GENIUS NM3G NITROGEN GENERATOR Manufacturer, Supplier, Exporter

The Genius NM-3G Nitrogen Generator is designed specifically for use with any LC/MS instrument. This Premium model offers safeguards that are unique to Peak Scientific generators and effectively deliver reassurance and confidence for critical functions. The Genius NM3G replaces the N110DR and the N110DR Hi-Flo.

TECHNICAL SPECIFICATIONS

Nitrogen 30 L/min @ 6.9 bar - 1.059 CFM @ 100 psi Min/ Max Operating Temperature 5C - 30C / 41F - 86F Max Relative Humidity 70% Maximum Altitude 2000 Meters Particles < 0.01m Gas Outlets 1/4 1 Phthalates None Suspended Liquids None Noise Level 54 dB(A) @ 1m Electrical Requirements 230v 50/60Hz 9.5A Power Consumption 2185 watts Dimensions (cm/ ins) WxDxH 90 x 73 x 75.3 / 35.4 x 28.7 x 29.6 Weight (kg/ lbs) 145 / 319 Nitrogen 30 L/min @ 6.9 bar - 1.059 CFM @ 100 psi Min/ Max Operating Temperature 5C - 30C / 41F - 86F Max Relative Humidity 70% Maximum Altitude 2000 Meters Particles: < 0.01m Gas Outlets 1/4 1 Phthalates None Suspended Liquids None Noise Level 54 dB(A) @ 1m Electrical Requirements: 230v 50/60Hz 9.5A Power Consumption 2185 watts Dimensions (cm / ins) WxDxH: 90 x 73 x 75.3 / 35.4 x 28.7 x 29.6 Weight (kg/ lbs) 145 / 319

Model name : Genius NM3G Gases produced: Nitrogen Applications: LCMS, LCMSMS

TECHNICAL SPECIFICATIONS

Model name : Genius NM3G
Gases produced: Nitrogen
Applications: LCMS, LCMSMS
