Tablet Disintegration Test Apparatus
Tablet Disintegration Test Apparatus
Price And Quantity
- 1
- Piece/Pieces
- 5000 INR
Product Description
Tablet Disintegration Test Apparatus
TECHNICAL SPECIFICATIONS:
Micro controller based circuitry to precisely control, indicate and program temperature of water bath and beaker individually.
`PAUSE' facility: This facility permits chemist to check disintegration state of the tablets intermittently and continue test without disturbing the test parameters.
Equipped with maintenance free single stepper motor.
All parameters like- Set Test Time, Actual Test Time, Temperature, Heater's `ON/OFF' state etc, are indicated on graphic LCD display screen.
Protection for over temperature for Heater through software and hardware.
Facility to measure stroke length while test is on.
Beaker temperature of both baskets displayed individually.
Test reports print all the detailed test parameters such as Temperature, Batch No, and Product ID etc. with ON-LINE or OFF-LINE printing facility.
Facility to print companys name on test report.
Optically isolated electronic heater driver.
Facility to review set parameters.
Non volatile memory.
Date selection in off line printing.
IQ, OQ documents will be provided with the instrument.
Validation of cycles / Min. with On/Off line printing facility
TECHNICAL DETAILS:
Number of beakers: 2 (1000 ml Glass Beakers).
Number of baskets: 2 (Each containing 6 glass tubes and 6 guided discs, designed as per USP, IP and BP standards).
Number of cycles: 30 cycles/min.
Stroke length: 55 2 mm.
Power supply: 230V, 50Hz, 1 KW max.
Timer maximum interval setting: 4 Hours.
Temperature range: Room Temperature to 40C.
Temperature resolution: 0.2 C.
Dimensions (L x W x H): 390 x 360 x 570 mm
Weight: 15 Kg.
Informative 128 x 64, blue graphic LCD display.
Input: Tactile Keypad
Memory to store 25 tests method parameters like disintegration time, temperature, alarm time and print interval.
Compatible with DOT MATRIX printer.
TECHNICAL SPECIFICATIONS:
Micro controller based circuitry to precisely control, indicate and program temperature of water bath and beaker individually.
`PAUSE' facility: This facility permits chemist to check disintegration state of the tablets intermittently and continue test without disturbing the test parameters.
Equipped with maintenance free single stepper motor.
All parameters like- Set Test Time, Actual Test Time, Temperature, Heater's `ON/OFF' state etc, are indicated on graphic LCD display screen.
Protection for over temperature for Heater through software and hardware.
Facility to measure stroke length while test is on.
Beaker temperature of both baskets displayed individually.
Test reports print all the detailed test parameters such as Temperature, Batch No, and Product ID etc. with ON-LINE or OFF-LINE printing facility.
Facility to print companys name on test report.
Optically isolated electronic heater driver.
Facility to review set parameters.
Non volatile memory.
Date selection in off line printing.
IQ, OQ documents will be provided with the instrument.
Validation of cycles / Min. with On/Off line printing facility
TECHNICAL DETAILS:
Number of beakers: 2 (1000 ml Glass Beakers).
Number of baskets: 2 (Each containing 6 glass tubes and 6 guided discs, designed as per USP, IP and BP standards).
Number of cycles: 30 cycles/min.
Stroke length: 55 2 mm.
Power supply: 230V, 50Hz, 1 KW max.
Timer maximum interval setting: 4 Hours.
Temperature range: Room Temperature to 40C.
Temperature resolution: 0.2 C.
Dimensions (L x W x H): 390 x 360 x 570 mm
Weight: 15 Kg.
Informative 128 x 64, blue graphic LCD display.
Input: Tactile Keypad
Memory to store 25 tests method parameters like disintegration time, temperature, alarm time and print interval.
Compatible with DOT MATRIX printer.
Trade Information
- 5-10 piece Per Month
- 6-8 Week
